04 Gm Negative Enteric Bacilli

Klebsiella, Enterobacter, Serratia

_..

  • O2 mask: Pneumonia

  • bag of urine: Urinary tract infection

  • Pills on ground: Multidrug resistant, treatment with carbapenem

  • hospital room: nosocomial infections, thus multi drug resistance

  • milk: Lactose fermenter

  • pink milk cartoon: Pink on MacConkey Agar

Enterobacter cloacae

_..

  • enterodactyl

  • flying: motile

Serratia marcescens

_..

  • triceratops

  • charging with arm up: Motile

  • red color: Produces red pigment on culture

  • catalase positive

Klebsiella pneumoniae

_..

  • ankylosaurus with clubbed tail/ kleb tail

  • mucous on back: polysaccharide capsule

  • NH3 bottle spraying kleb: Urease positive

  • all 4 feet: Immotile

  • clear zone and thick capsule

_..

  • 3 A's: Alcoholics, abscesses, aspiration (started from aspiration)

  • knocked over jar of currant jelly: "Currant" jelly sputum

  • Xray: Cavitary lesion, may look like TB

  • Liver abscess via ascending cholangitis

  • The hallmark of Klebsiella pneumonia is a thick, mucoid, blood-tinged sputum (currant jelly sputum) and lung tissue necrosis with early abscess formation.

Salmonella

_..

  • macrophage cage: Facultative intracellular within macrophages

  • fish tail floppy: Salmonella is motile

  • lemon cut: Acid-labile

  • black plate: H2S positive, black colonies on Hektoen Agar plate

  • fish bone: Osteomyelitis

  • capsule: vi Capsule, inhibit phagocytosis

_..

  • flower: Fluoroquinolones treatment (ie Cipro)

_..

  • syringe: Live attenuated vaccine

Enteritidis

_..

  • left chicken: The reservoir for Salmonella enteritidis is the chicken

  • match: Inflammatory diarrhea

  • syringe bulb: Type III secretion system

Typhi

_..

  • right: Salmonella typhi

  • sickle: In Sickle Cell disease

  • seagull: Salmonella typhi in the gallbladder of chronic carriers

  • cook drape: Typhoid Mary

  • drape: Rose colored macules

  • Green pea: "Pea soup" diarrhea

Shigella

_..

  • standing on acid: Acid stable

  • green shirt: Green colonies on Hektoen agar

  • chained to stone: Immotile

_..

  • actin projectile: Use of actin filaments

  • M: Invasion of M cells

_..

  • Flame all around: Inflammatory diarrhea

  • Red stool: blood in stool

HUS:

  • whip: Glomerular damage first

  • plates: thrombosis with platelet, drop in platelet counts

  • popped balloon: platelet aggregation lyse RBC, Red blood cell hemolysis

  • young kid: HUS common in young children

_..

  • 60a timer: Toxin binds to 60S subunit of ribosomes

  • syringe with bulb: Type III Secretion System

E. Coli

_..

  • cat: Catalase positive

  • milk bottle: Lactose fermenter

  • pink milk bottle: Pink on MacConkey Agar

  • capsule with cake: Encapsulated

  • K cake: K Antigen

  • green drink holder: Green on EMB agar

  • type III secretion

_..

  • milkshake with red strawberry: leading cause of sepsis via LPS

  • hair bow: Fimbriae, pili like, cause for UTI

  • UTI cup with #1: Most common cause of UTI

  • neonate with helmet: Neonatal meningitis

  • neonate points to cake: Only if it has K antigen

EHEC

_..

  • shiga toy: Shiga-like toxin can cause HUS

  • Only $1.57: O157:H7 antigen is associated with outbreaks

  • hamburger: Transmitted by eating undercooked meat

  • ketchup on table and red stool: Bloody diarrhea

  • sorbitol bottle: Does NOT ferment sorbitol

  • balloon string: Damages endothelial cells in the glomerulus

  • plates: Platelet aggregation follows and decrease in platelet count

  • Popped balloon: Red blood cell hemolysis via the thrombosis

ETEC

_..

  • traveller truck: Traveler's diarrhea

  • water truck: Transmitted via water

  • LA: L = Labile, A = cAMP

  • SG: S= Stable G = cGMP

  • water truck: Watery diarrhea

Yersinia

Yersinia Enterolitica

_..

  • English terrier: yersinia enterolitica

  • ice on window: Resistant to cold temperatures

  • Safety pin: Bipolar staining, sometimes described as having a safety pin appearance

  • glass capsule: Encapsulated

_..

  • poop in cage: Y. enterocolitica transmitted through puppy feces

  • milk bottle: May be transmitted through contaminated milk products

  • baby: Toddlers are commonly affected by Y. enterocolitica

_..

  • red stool: bloody stool

  • right abdomen toddler : Infection can mimic appendicitis symptoms

Yersinia Pestis

_..

  • Pink color: Gram negative organism

  • Rodents in cage: Prairie dogs main reservoir in United States

  • flea sign: Transmitted by flea bites

_..

  • sai: Streptomycin (with tetracycline) for treatment

  • mouse wheel: Tetracyclines (with streptomycin) for treatment

_..

  • syringe bulb: Yops (yersinia outer protein) secreted via type III secretion systems, stops phagocytosis

_..

  • guy with buboes: Characteristic buboes form on skin

  • Uncontrolled spread can cause organ abscess, cutaneous hemorrhage, and tissue necrosis

_..

  • killed vaccine sign: Killed vaccine can be used to prevent transmission

Campylobacteria Jejuni

_..

  • curved moustache: Curved/spiral gram negative rod

  • flame: Grows at 42 degrees C

  • chicken roasted: Poultry reservoir. Can be transmitted from domestic animals (pet dog)

  • ring: Oxidase positive

_..

  • red stool: Causes bloody diarrhea

  • bear cub invading cooler: Invasive, bacteremia, sepsis

  • slapping knee: Reactive arthritis, seronegative

  • bear playing with sausages: Guillain-Barre syndrome - Ascending paralysis

Vibrio

_..

  • blue ring: Oxidase positive

  • comma mustache: Comma shaped

  • red boat: Gram negative

  • lemon sliced: Acid labile because grows on alkaline media

  • base camp map: Grows on alkaline media

_..

  • boat attached: Fimbrae attachment, does not invade

  • Base camp map: Increases cAMP

  • Gs bottle: Toxin activates Gs pathway and cAMP, increase water secretion

_..

  • bathroom: Fecal-oral transmission

  • rice farms: Rice water stools

  • water: Watery diarrhea

  • general drinking water: Oral rehydration therapy

_..

  • Vibrio vulnificus/parahemolyticus: oysters on plate, contaminated sea food

Helicobacter

_..

  • ammonium bottle: Urease positive, splits urea into ammonia and CO2, reduce acidity for invasion (urease breath test)

  • helicopter blade: Motile, spins around with flagellum

  • curved mustache: Curved/spiral gram negative rod

  • blue ring: Oxidase positivex

  • silver headphones: silver stain

  • catalase positive

_..

  • bullet holes and duodenum letters: Duodenal ulcers

  • crab: Increased risk of gastric adenocarcinoma

  • pile of tissues with mucous: Mucosa associated lymphoid tissues (MALT)

_..

  • gasoline pump: Proton Pump Inhibitor (PPI)

  • ammo box: Amoxicillin

  • keep clear crows: Clarithomycin

Pseudomonas

_..

  • cat: Catalase positive

  • red bathtub: Gram negative rod

  • blue ring: Oxidase positive

  • glass capsule: Encapsulated

  • grapes on table: Produces fruity grape odor

  • air bellow: Obligate aerobe

  • water in red tub: Thrives in aquatic environment

  • blue/green residue: Produces blue-green pigment (from pyocyanin and pyoverdin)

  • motile

  • type 3 secretion

_..

  • Nurse coughing and pouring Cl water: Nosocomial pneumonia and respiratory failure in cystic fibrosis patients due to Cl mutation

  • fish bone next to candy and mortar: Osteomyelitis in diabetics (traumatic injury) and IV drug users (directly introduce via needles)

  • maid on fire: Infection associated with burn patients

  • chamber pot: Nosocomial urinary tract infections

  • Hot tub folliculitis: red, itching, pustular folliculitis association with hot tub

  • dog with black spot: Ecthyma gangrenosum - black necrotic lesions on skin (from toxins)

  • Maid listening with trumpet outside ear: Otitis externa. Swimmer's ear

_..

  • Guy wearing green with bow: Toxin inactivates EF-2 by ribosylation (Same mechanism as Diphtheria toxin)

_..

  • Piper: Piperacillin for treatment

  • flower: Fluoroquinolones, great for UTI

  • sai: Aminoglycosides, good with tetracycline

Proteus mirabilis

_..

  • red: gm negative

  • NH3: Urease positive, makes ammonium/CO2, alkaline environment, responsible for struvite stones precipation

  • octopus: Swarming motility when plated

  • Fish all around: Fishy odor

_..

  • horn of stag: Forms staghorn calculi in renal stones

  • Stone in hand: Alkaline environment can cause struvite stone production

  • Guy urinating: May cause UTI

_..

  • Eggs: Treat with sulfonamides
